Model |
RT1K-C |
RT1KL-C |
RT2K-C |
RT2KL-C |
RT3K-C |
RT3KL-C |
RT6K-C |
RT6KL-C |
RT10K-C |
RT10KL-C |
|
|
Rated Power |
VA/W |
1KVA/800W |
1KVA/800W |
2KVA/1600W |
2KVA/1600W |
3KVA/2400W |
3KVA/2400W |
6KVA/4800W |
6KVA/4800W |
10KVA/8KW |
10KVA/8KW |
|
Input |
Phase |
Single Phase with Ground |
|||||||||
|
|
Nominal Voltage |
200/208/220/230/240VAC |
|||||||||
|
|
Voltage Range |
110 ~ 300VAC |
120~ 275VAC |
||||||||
|
|
Frequency Range |
50Hz:46 ~ 54Hz |
40 ~ 70Hz |
||||||||
|
|
Power Factor |
0.98 |
0.99 |
||||||||
|
|
Connection |
IEC320-10A inlet |
IEC320-16A inlet |
Terminal Block |
|||||||
|
Output |
Phase |
Single Phase |
|||||||||
|
|
Voltage |
200/208/220/230/240VAC ± 1% |
|||||||||
|
|
Frequency |
50/60Hz adjustable,46~54Hz (Line mode) |
|||||||||
|
|
|
50Hz ± 0.2%Hz ( Battery mode) |
|||||||||
|
|
Waveform |
Pure Sine Wave |
|||||||||
|
|
Overload Capability |
105%～150% 45S～25S then turn to bypass output ; |
Load﹤105% work consistant;105%﹤load﹤125% 1min;125%﹤load﹤150% 30sec |
||||||||
|
|
Current Crest Ratio |
3:1 |
|||||||||
|
|
Connections |
IEC320 -10A * 6 |
IEC320 -10A *6 |
IEC320 -10A * 8 |
IEC320 -10A *8 |
IEC320 -10A *8 |
IEC320 -10A *8 |
Terminal Block |
|||
|
Bypass |
Automatic Transfer |
on overload and UPS failure |
|||||||||
|
|
Before UPS Power-on |
Default “ON”, user adjustable to “YES” |
Yes |
||||||||
|
Transfer Time |
0 ms; less than 4 ms from inverter to bypass and vice versa |
Zero |
|||||||||
|
LCD+LED display |
UPS status, Battery capacity, loading, Fault code |
||||||||||
|
Audible Alarm |
|||||||||||
