MODEL

95M500/50X

95M300/50X

95M200/50X

95M100/50X

95M400/40X

95M240/40X

95M160/40

X95M8040X

System Capacity

500KVA

300KA

200KVA

100KVA

400KVA

240KVA

180KVA

80KVA

Power Module Capacity

50KVA45KW

40KVA40KW

lnput

Dual tnput

Standard   Optional  Standard   Optional  Standard

Phase

3 Phase+Neutral+Ground,380V/400V/415V(Eine-line)

lnput Voltage Range

304~478Vac (line-tine).full load;
228V-304Vac(tine-line).load decreases linearfly according to the min phase voltage

Rate Frequency

50/60Hz

lnput Frequency Range

40Hz~70Hz

lnput PF

>0.99

Input THDi

<3%( 100% Linear load)

Bypass

Rate Voltage

380/400/415Vac (line-line)

Rate Frequency

50/60Hz

Input Voltage Range

Seltable，-40%~+25%

Bypass Frequency Range

Settable,±1Hz,±3Hz,±5Hz

Bypass Overload

110% long term cperation
130S for 5 mins
150% Tor imin
>150% or 1s

125% kong tem operaion
130 lor 10 mins
150%sor 1min
>150% sor 300ms

110% long term eparasian
125% for 5mins
150% lor 1min
>150% for 1s

125% bong term operaion
130% hor T0 mins
150% for 1 min
>150% for 300ms

Output

Rate Voltage

380/400/415Vac (line-line)

Voltage Regulation

1% for balanoe load; 1.5% for unbalance load

Rate Frequency

50/60Hz

Frequency Precision

0.1%

Output PF

0.9

1

Output THDu

<1%,Linear load;<5.5%,Non-linear load

Crest Factor

3:1

lnverter Overload

110% for 1 hour;125% for 10 mins ;150% for 1 min; >150%for 200 ms

Battery

Voltage

士240Vdc

Battery Number

40pcs (Settable: even number from 32 to 44)
