MODEL

93M600/30X

93M300/30X

93M180/30X

93M500/25X

93M250/25X

93M150/25X

System Capacity

600kVA

300kVA

180kVA

500VA

250kVA

150kVA

Power Module Capacity

30kVA/27kW

25kVA/25kW

Input

Dual Input

Optional

Phase

3 Phase+Neutral+Ground, 380V/400V/415V(line-line)

Input Voltage Range

304~478Vac (line-line),full load; 228V~304Vac (line-line),load decreases linearly according to the min phase voltage

Rate Frequency

50/60Hz

Input Frequency Range

40Hz～70Hz

Bypass

Input PF

>0.99

Input THDi

<3% （100% Linear load）

Rate Voltage

380/400/415VAC  (line-line)

Rate Frequency

50/60Hz

Input Voltage Range

Settable, -40%～+25%

Output

Bypass Frequency Range

Settable, ±1Hz, ±3Hz, ±5Hz

Bypass Overload

110% long term operation; 125% for 5 mins ;150% for 1 min; 400% for 1s

Rate Voltage

380/400/415VAC  (line-line)

Voltage Regulation

1% for balance load; 1.5% for unbalance load

Rate Frequency

50/60Hz

Frequency Precision

0.1%

Output PF

0.9

1

Output THDu

<1% , Linear load; <5.5%, Non-linear load

Crest Factor

3:1

Battery

Inverter Overload

110% for 1 hour; 125% for 10 mins ;150% for 1 min; >150% for 200 ms

Voltage

±240VDC

Battery Number

40pcs (Settable: even number from 32 to 44)±1%

Voltage Precision

Charge Power

up to 20% * Output active power
