Model

CX1K

CX1KL

CX2K

CX2KL

CX3K

CX3KL

Capacity

VA/W

1000VA/900W

1000VA/900W

2000VA/1800W

2000VA/1800W

3000VA/2700W

3000VA/2700W

Input

Nominal Voltage

200/208/220/230/240VAC

Voltage Range

115～300VAC

Harmonic Distortion

<10% (Nonlinear load)

Power Factor

0.98

Frequency Range

50Hz:46~54Hz; 60Hz:56~64Hz

Output

Voltage

200/208/220/230/240(1±1%)VAC

Frequency

50/60Hz (Adjustable);
50Hz AC Mode: Follow AC Mode (AC Range 46~54Hz); Battery Mode: 50Hz (1±0.2%)
60Hz AC Mode: Follow AC Mode (AC Range 56~64Hz); Battery Mode: 60Hz (1±0.2%)

Wave Form

Pure sine wave

Power Factor

0.9

Harmonic Distortion

≤4% (Linear load); ≤7% (Nonlinear load)

Overload Capacity

105%～150%  45S～25S; 150%～200%  25s～300ms; ≥200%  200ms

Current Crest Ratio

3∶1

Connections

IEC320*4

Efficiency

Battery Mode

81%

83%

AC Mode

85%

87%

Battery

Type

Sealed free maintenance lead acid battery

Nominal DC voltage

24VDC

36VDC

48VDC

72VDC

72VDC

96VDC

Quantity

12VDC×2

12VDC×3

12VDC×4

12VDC×6

12VDC×6

12VDC×8

Backup Time (Full Load)

﹥2.5min

(Built in batteries12V9AH)

Depends on requested

Back-up time

﹥5min

(Built in batteries12V 9AH)

Depends on requested

Back-up time

﹥4.5min

(Built inbatteries12V7AH)

Depends on requested

Back-up time

Charge Current (Max)

1A

5A

1A

5A

1A
