Model

GS 1000

GS 2000

GS 3000

Power Rating

1000W

2000W

3000W

Nominal input Voltage

120/230VAC

Low Line Disconnect

85Vac±4%(Normal) or 80Vac±4%(Wide) for 120Vac

184Vac±4%(Normal) or 135Vac±4%(Wide) for 230Vac

Low Line Re-connect

95Vac±4%(Normal) or 85Vac±4% (Wide) for 120Vac

194Vac±4%(Normal) or 145Vac±4%(Wide) for 230Vac

High Line Disconnect

136Vac±4%(Normal) or 145Vac±4%(Wide) for 120Vac

263Vac±4%(Normal) or 263Vac±4%(Wide) for 230Vac

Max AC input Voltage

120Vac for Max150Vac, 230Vac for Max270Vac

Frequency

50Hz:41-54Hz,60Hz:51-64Hz

Nominal Charge Current

20A/35A/50A/70A/90A(5 stages adjustable charging current)

Over Charge Protection

Bat.V>15.5VDCfor 12V battery ； Bat.V>31.0VDC for 24V battery, Bat.VN62.0VDC for 48V battery ； beeps 0.5s every 1s & fault after 60s

Rated Charge Current

40A

60A

60A

PV Input Voltage range

12VDC. 25VDC-75VDC for 24VDC. 55-145VDC for 48V

Max.PV open circuit array voltage

12V for40VDC, 24V for 75VDC, 48V for 145VDC

Charger mode

MPPT

PV Low Voltage Disconnect

PVWBat.V

Efficiency

>97%

Nominal Charger Current

20A/35A/50A/70A/90A(According to the inverter model), 5 stages adjustable charging current

Over charge Protection

Bat.V>15.5VDC/31VDC/62VDC,beeps 0.5s every 1s & fault after 60s

Efficiency (Battery Mode )

>87%

Efficiency(Line Mode)

>98%

Nominal DC Input Voltage

12/24/48VDC

Over-Load Protection

110%<load<150%, beeps 0.5s every 1s, and Fault after 60s off the output, load>150%, beeps 0.5s every 1 s, and Fault after 20s

Power Saver

Load<25W(Enabled on "P/S auto"Setting of Remote control)

Protections

Low battery.over charging,over load,over temp

Indicators

LED+LCD Display

Operating Temperature Range

0°C to 40°C

Storage Temperature

-15°C 〜60°C

Operation humidity

5% to 95%(non-condensing)

Audible Noise

60dB max

Dimension(L*W*H)

480x336x190mm

Net Weight(kg)

19.5

23.5

28.0
